101 Reverb

Featuring an interesting new take on the usual three-knob EQ section, the Bass and Treble controls use traditional “tone stack” technology, yielding a familiar bright chime based on 50 years of tradition, while the active Mid control provides a more strongly voiced cut/boost function for increased versatility. Increasing the Mid control boosts the frequencies that give an aggressive “D-Style” bite to the sound, while decreasing Mid brings out that familiar clean-60’s Blackface tone.

Weighing only 2 pounds the 101 reverb is so light you'll think we forgot to put the guts in! Even with the same compact footprint, it has more than enough power to bring any cabinet to life!

Fits in our Block Case 2.0!

• Features
  • Up to 50 watts
  • 3 band EQ (Bass/Mid/Treble)
  • Gain
  • Limiter
  • Reverb
  • Effects Loop
• Controls
  • Primary Controls
  • GAIN adjusts the distortion from clean to overdrive.
  • LIMITER reduces gain just enough to prevent overdrive, and then restores gain as the note dies away.
  • 3-BAND ACTIVE EQ Boosts and cuts Bass, Mids, and Treble frequencies.
  • Effects Controls
  • EFFECTS LOOP send and return jacks.
  • REVERB
  • Volume Controls
  • MASTER adjusts speaker power volume level. (0-50watts)
• Specifications
  Electronic Performance

  Input	¼" mono, 2M input impedance, 2V peak
  Effects Send	¼” mono, 1V full scale, 600 ohms
  Effects Return	¼” mono, 1V full scale, 47K
  Headphone Output	1/4" jack, 4V peak

  Power

  Power Output	0 to 50 watts maximum, 4-8 ohms
  AC Power Req.	100-240Vac, 50-60 Hz, 100 W maximum
  Speaker 1 Output	8 ohms, 60-100 W recommended rating
  Speaker 2 Output	4 ohms, 60-100 W recommended rating
  Dual Speakers 1+2	8 ohms each, 30-50W recommended rating

  Dimensions


  HxWxD	8.5”(218mm) x 7.5” (190mm) x 3” (76mm)
  Weight	2 lbs (0.9kg)




• Resources
  • The Manual contains detailed info for setup and technical specs.
